1. Introduction

Probabilistic Relational Models (PRMs) are a fully object-oriented extension of Bayesian Networks (BNs). Both PRMs and BNs are one of the many Probabilistic Graphical Models. In this introduction, we will offer a very short introduction to both models. For further reading, we suggest the reader to lookup the references in the Bibliography section.

1.1. Bayesian Networks

Bayesian Networks represent discrete probability distributions using a directed graph and parameters called Conditional Probability Tables. The nodes of the graph represent discrete random variables and the arcs represent probabilistic dependencies between those variables (to be precise, the lack of an arc between two nodes represents a conditional independence between the corresponding random variables). To each node is assigned the Conditional Probability Tables (CPTs) of the node given its parents in the graph, and the joint probability distribution over all the nodes/variables in the graph is equal to the product of all the CPTs.

../_images/water_sprinkler.png

The Water Sprinkler is a classic example of a Bayesian Networks. Its purpose is to infer whether the grass in a garden is wet because of the rain or because the house’s owner forgot to turn off the water sprinkler.

The probability distribution is defined over four Boolean random variables: Cloudy, Sprinkler, Rain and Wet Grass. There are also four CPTs representing the following conditional distributions: P(Cloudy), P(Sprinkler|Cloudy), P(Rain|Cloudy) and P(Wet Grass | Sprinkler, Rain).

We won’t go further in our introduction of Bayesian Network and if you never heard of Bayesian Networks, you might need to first familiarize with them before using O3PRM. A good place to start is the pyAgrum tutorials that you can find at http://agrum.gitlab.io.

1.2. Probabilistic Relational Models

Bayesian Networks suffer from the same issue that had early programming languages: the larger the network, the harder it is to create it and to maintain it. Naturally, the BN community looked at the solutions provided by the language programming community and found several paradigms to extend BNs: first order logics, entity-relation models, object oriented paradigms, etc. There is no current consensus on which BN extension is the best as each one offers specific features lacking in the other paradigms.

Probabilistic Relational Models are one of several Object Oriented extensions of Bayesian Networks. They offer a good implementation of the Object Oriented paradigm while not diverging too much from the Bayesian Networks framework. Their precise definition is provided in subsequent sections of this documentation. But, for the moment, just keep in mind the fact that they are an object-oriented extension of BNs.

1.3. Implementation

The aGrUM framework offers an implementation of the O3PRM language. You can either directly use aGrUM, which is written in C++, its Python wrapper pyAgrum or the prm_run application shipped with aGrUM’s source code. All resources and installation instructions can be found at http://agrum.gitlab.io.
